Specifications

Product code S53UG+5HaxD2HaxD-TC&RG650E-EU

Architecture ARM 64bit

CPU IPQ-6010

CPU core count 4

CPU nominal frequency 864-1800 MHz

CPU Threads count 4

Switch chip model IPQ-6010

RouterOS license 4

Operating System RouterOS v7

Size of RAM 1 GB

Storage size 128 MB

Storage type NAND

MTBF Approximately 200'000 hours at 25C

Tested ambient temperature -40°C to 70°C

Powering

Number of DC inputs 1 (DC jack)

DC jack input Voltage 12-28 V

Max power consumption 27 W

Max power consumption without attachments 18 W

Cooling type Passive

Mobile

3G Category R8 (42.2Mbps Downlink, 5.76Mbps Uplink)

3G bands 1 (2100MHz)

5 (850MHz)

8 (900MHz)

LTE Category 20 (2.0 Gbps Downlink, 211 Mbps Uplink)

MIMO DL 4x4

MIMO UL 1x1 (5G SA MIMO UL 2x2)

LTE FDD bands 1 (2100MHz)

3 (1800MHz)

5 (850MHz)

7 (2600MHz)

8 (900 MHz)

20 (800MHz)

28 (700MHz)

32 (1500 MHz)

LTE TDD bands 38 (2600MHz)

40 (2300MHz)

41 (2500MHz)

42 (3500MHz)

43 (3700MHz)

5G NSA FDD bands 1 (2100 MHz)

3 (1800 MHz)

5 (850 MHz)

7 (2600 MHz)

8 (900 MHz)

20 (800 MHz)

26 (850 MHz)

28 (700 MHz)

67 (700 MHz)

75 (1500 MHz)

76 (1500 MHz)

5G NSA TDD bands 38 (2600 MHz)

40 (2300 MHz)

41 (2500 MHz)

77 (3700 MHz)

78 (3500 MHz)

5G SA FDD bands 1 (2100 MHz)

3 (1800 MHz)

5 (850 MHz)

7 (2600 MHz)

8 (900 MHz)

20 (800 MHz)

26 (850 MHz)

28 (700 MHz)

67 (700 MHz)

75 (1500 MHz)

76 (1500 MHz)

5G SA TDD bands 38 (2600 MHz)

40 (2300 MHz)

41 (2500 MHz)

77 (3700 MHz)

78 (3500 MHz)

TAC 86896506

Wireless specifications

Wireless 2.4 GHz Max data rate 574 Mbit/s

Wireless 2.4 GHz Number of chains 2

Wireless 2.4 GHz standards 802.11b/g/n/ax

Antenna gain dBi for 2.4 GHz 3

Wireless 2.4 GHz chip model QCN-5022

Wireless 2.4 GHz generation Wi-Fi 6

Wireless 5 GHz Max data rate 1200 Mbit/s

Wireless 5 GHz Number of chains 2

Wireless 5 GHz standards 802.11a/n/ac/ax

Antenna gain dBi for 5 GHz 6

Wireless 5 GHz chip model QCN-5052

Wireless 5 GHz generation Wi-Fi 6

Ethernet

10/100/1000 Ethernet ports 4

Number of 2.5G Ethernet ports 1

Peripherals

Number of SIM slots 1 Modem (Micro SIM)

Number of USB ports 1

USB Power Reset Yes

USB slot type USB type A

Max USB current (A) 1.5

Other

CPU temperature monitor Yes

PCB temperature monitor Yes

Voltage Monitor Yes

Mode button Yes

eSIM Yes

Certification & Approvals

Certification CE, EAC, ROHS

IP 20
