Technikai információ

GameVoice Mix

    PS4 and PS5 (PS5 requires optional HDMI to SPDIF converter)



Controls

    Master volume dial, GameVoice Mix dial, Headphone gain switch, SBX button, Mode Button, HP / SPK Button, Opt-In / HDMI ARC mode switch



Dimensions

    125.7 x 90.7 x 52.4 mm



Headphone Amp

    Output Impedance: 1Ω



Audio Technology

    CrystalVoice, Sound Blaster Acoustic Engine, GameVoice Mix, Discrete Xamp Bi-amplifier, Dolby Audio



Max. Playback Quality

    Direct Mode:

    Playback (Stereo): Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz, 176.4 kHz, 192.0 kHz, 352.8 kHz, 384.0 kHz

    Playback (5.1/7.1): Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz, DSP Mode:

    Playback (Stereo): Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz, 176.4 kHz, 192.0 kHz, 352.8 kHz, 384.0 kHz

    Playback (5.1/7.1): Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz



Recording Resolution

    Mic-in: Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz, 176.4 kHz, 192.0 kHz

    Optical In: Up to 192.0 kHz

    Line-in: Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz, 176.4 kHz, 192.0 kHz

    What-U-Hear: Up to 16/24/32-bit, 44.1 kHz, 48.0 kHz, 88.2 kHz, 96.0 kHz, 176.4 kHz, 192.0 kHz



Platform

    USB 2.0, USB 3.0



Connectivity Options (Main)

    1 x TOSLINK Optical In, 1 x TOSLINK Optical Out, 1 x 3.5 mm Line-in, 1 x 3.5mm Line-out, 1 x 3.5 mm Mic-in, 1 x USB C (USB-1) power/data jack for PC/Mac/Consoles, 1 x USB C (USB-2) power/data jack for Consoles and mobile devices, 1 x 4-pole Headset jack (3.5mm, CTIA), 1 x HDMI ARC



Headphone Amp

    Output Impedance: 1Ω



Max Channel Output

    Stereo



Supported Operating Systems

    Windows® 10, macOS 10.15 and above, Windows® 11



Included Accessories

    2 x USB-C to USB-C Cable



DAC

    Dynamic Range (A-Weighted) : 130dB, THD+N : 0.00018%



ADC

    Dynamic Range (A-Weighted) : 114dB, THD+N : 0.00056%



Power

    USB 2.0 / 3.0, USB Bus Powered



Recommended Usage

    Gaming



System Requirements

Windows



    Intel® i3 or AMD® equivalent processor

    Intel, AMD or 100% compatible motherboard

    Microsoft® Windows 11, Windows 10 32/64 bit ver 21H1 or later

    > 4GB RAM

    > 4GB of free hard disk space

    Available USB-C port (USB 2.0)

    PC must meet the minimum hardware requirements to operate on the Windows OS installed



Macintosh



    Apple Silicon M-series Processor

    Macintosh running MacOS 10.15 or higher

    > 4GB RAM

    > 4GB of free hard disk space

    Available USB-C port (USB 2.0)



Mobile Device



    Android 13.0 or later

    iOS 15 or later

    Available USB-C port (USB 2.0)

    Device must capable of output audio through its USB-C port



PS4



    Firmware Ver 5.0 or later

    Available USB-A port ^ (USB 2.0)



PS5



    Firmware Version 20.02-2.26.00.00-00.00.00.0.1 or later

    Available USB-C port

    Available HDMI ARC port via TV



Xbox Series X/S



    System OS 10.0.19041.5496 or later

    Available HDMI ARC port Via TV



Nintendo Switch



    Switch OS 5.0 or later

    Available USB-C port (USB 2.0)



Package Contents



    1 x Sound Blaster G8

    1 x QSG/Warranty/Compliance Leaflet

    2 x USB-C to C cable (1.5m)
