Technikai információ

Kamera

Képérzékelő 1/2.7” Progressive Scan CMOS

Shutter Speed 1/3 to 1/10000 s

Slow Shutter Yes

Min. szükséges megvilágítás 0.005 Lux; 0 Lux with IR/white light

Day/Night Mechanism IR Cut Filter

Day/Night Switch Day/Night/Auto/Schedule-Switch

LENS

Type Fixed Focal Lens

Focal Length 2.8/4 mm

Aperture 2.8 mm: F1.6

4 mm: F1.6

FOV 2.8mm:

Horizontal FOV: 109°, Vertical FOV: 57°, Diagonal FOV: 128°

4mm:

Horizontal FOV: 90°, Vertical FOV: 48°, Diagonal FOV: 107°

Lens Mount M12*P 0.5

DORI Distance 2.8 mm

Detect: 64 m (209 ft)

Observe: 27 m (87 ft)

Recognize: 13 m (42 ft)

Identify: 6 m (21 ft)

4 mm

Detect: 80 m (262 ft)

Observe: 33 m (109 ft)

Recognize: 16 m (52 ft)

Identify: 8 m (26 ft)

Angle Adjustment (Manual)

Range Pan: 0° to 360°, Tilt: 0° to 85°

ILLUMINATOR

IR LED Quantity: 1

Range: 30m

Wavelength: 850nm

White LED Quantity: 1

Range: 30m

Illuminator On/Off Control Auto/Scheduled/Always on/Always off

VIDEO

Max. Resolution 2880 X 1620

Main Stream Frame Rate:

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

2880x1620,2688x1520, 2304x1296, 2048x1280, 1920x1080,1280x720

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Sub-Stream Frame Rate:

50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:

704x576,640x480, 352x288, 320x240

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.

Bit Rate Control CBR, VBR

Video Compression Main Stream: H.265+/H.265/H.264+/H.264

Sub-Stream: H.265/H.264

H.264 Type Main Profile/High Profile

H.264+ Main Stream Supported

H.265 Type Main Profile

H.265+ Main Stream Supported

Video Bit Rate Main Stream: 256 Kbps to 6 Mbps

Sub-Stream: 64 Kbps to 512 Kbps


Image Settings Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software

Image Enhancement BLC/3D DNR/HLC/SmartIR

Wide Dynamic Range 120 dB

SNR ? 52 dB

Image Parameters Switch Yes

Privacy Mask Up to 4 Masks

ROI 1 Region

OSD Setting Yes

Hang

Hangkommunikáció N/A

Hangbemenet Yes

Hangkimenet N/A

Hangtömörítés Yes

Audio Sampling Rate 8KHz

Environment Noise Filtering Yes

Audio Bit Rate 64 Kbps(G.711 alaw)

Hálózat

Szabvány TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS

ONVIF Yes

API Open Network Video Interface (Profile S)

Simultaneous Live View 3 Main Streams & 3 Sub-Streams

Client VIGI App, VIGI Security Manager, Web UI

Web Browser Google Chrome® 57 and above

Firefox® 52 and above

Safari® 11 and above

Microsoft® Edge 91 and above

Cloud Yes

Biztonság Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

Figyelmeztetési és eseménykezelési vezérlés

Smart Event Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection

Basic Event Motion Detection, Video Tampering Detection, Exception ( Illegal Login), Scene Change Detection

Alarm Linkage Memory Card Video Recording, Message Push, White Light Flashing

Linkage Method N/A

Output Notification Message Push

Deep Learning Function

People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Multi-Target-Type Detection Supports Simultaneous Detection and Capture of Human Body and Vehicle

Face Capture N/A

Face Comparison N/A

Fizikai kezelőfelület

Hálózati csatlakozás 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE

Alarm N/A

Reset Button Yes

Power DC Power Port

On-board Storage Built-In Memory Card Slot, Support MicroSD Card, up to 256 GB

Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera

Built-in Speaker N/A

Audio N/A

Általános

Operating Temperature -30–60 °C

Storage Temperature -40–60 °C

Operating Humidity 95% or Less (Non-Condensing)

Storage Humidity 95% or Less (Non-Condensing)

Csomagolás tartalma VIGI Network Camera

Quick Start Guide

Waterproof Cable Attachments

Mounting Accessories

Material Plastic

Net Weight 0.28 Kg

Gross Weight 0.47 Kg

Power Supply 12V DC ± 5%, Max. 7 W, 5.5mm Coaxial Power Plug

PoE: 802.3at, class 0, Max. 8 W

Protection IP67, IK10

Product Dimensions (L x W x H) ?115x85.7 mm

Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IC
